The electrode is characterized by smooth and stable arc, low spatter, easy slag detachability, fine rippled bead appearance, weld deposit possesses good chemical and mechanical properties.
| Typical Weld Metal Chemical Properties (Element %) | ||||
|---|---|---|---|---|
| Carbon (C) | Magnesium (Mn) | Silicon (Si) | Sulfur (S) | Phosphorus (P) |
| 0.65 MAX | 0.41 | 0.24 MAX | 0.011 MAX | 0.021 MAX |
| Current Polarity | Welding Position |
|---|---|
| DC(-), AC | FLAT, HORIZONTAL, VERTICAL, OVERHEAD |
| Typical Weld Metal Mechanical Properties (Element %) | |||
|---|---|---|---|
| Yield Strength (N/mm²) KSI | Ultimate Tensile Strength (N/mm²) ksi | Elongation (%) | CVN Impact at °C Joules |
| 425 (62) | 490 (71) | 26 | 0°C : 62 J |
| Size and Current Recommendations | ||
|---|---|---|
| Size D x L (mm) | Size D x L (in) | Current (Amps) DC-, AC |
| 2.5mm x 350mm | 3/32" x 14" | 50-80 |
| 3.2mm x 350mm | 1/8" x 14" | 80-130 |
| 4.0mm x 350mm | 5/32" x 14" | 130-170 |
Re-dry the electrode at 120°C for 30-60 minutes, for best results.
Note:
The information provided in this article or otherwise referred to herein is merely provided as “typical” without any assurance or promise. Actual results will vary based on a number of variables, including, but not limited to, weld process, plate chemistry and temperature, weldment design, and fabrication procedures. Washington Central Corporation expressly disclaims any liability suffered from any reliance thereon. It is advised that before using any welding consumable or procedure in the intended application, users check their compatibility through qualification testing or other suitable methods.
